Forges steel gate valve 800#
 Figure No. 9390 (Larger sizes available on application) |
Ratings (ASTM A105): |
|---|---|
| 1,975 psi at -20°F to 100°F | |
Test Pressure (API 598): |
|
| Hydraulic: Shell - 2,975 psi | |
| Seat: - 2,175 psi | |
| Air: Seat - 80 psi |
STANDARD MATERIALS |
|
|---|---|
Forging Material Body and Bonnet |
Trim Material |
| A105 | API Trim 8 |
| A182 F11 | API Trim 8 |
| A182 F22 | API Trim 8 |
| A182 F5 | API Trim 8 |
| A182 F9 | API Trim 8 |
| A182 F316 | API Trim 12 |
| A182 F316L | API Trim 12 |
| A350 LF2 | API Trim 8 |
